Welch Allyn Diagnostic Set
PanOptic Ophthalmoscope (#11810 head only)
The revolutionary
PanOptic provides easy entry into the eye, together with a wider field of view
to more easily observe conditions such as
hypertension, diabetic retinopathy, and papilledema.
Click for more details
- 5X larger view of the fundus vs. standard ophthalmoscopes in an undilated
eye
- 25º field of view vs. the standard 5º field of view
- Greater working distance improves comfort for both practitioner and
patient
- Patented Glare Extinguishment System prevents interference from unwanted
glare and reflections
- Halogen HPX lamp provides bright, white light
- Compatible with all existing Welch Allyn 3.5 V power sources
PanOptic Ophthalmoscope with Cobalt Blue Filter and Add-On Corneal Viewing Lens (head only)(# 11820)
The revolutionary PanOptic Ophthalmoscope provides
easy entry into the eye, together with a wider field of view to more easily
observe conditions such as papilledema and hemorrhages consistent with
shaken baby syndrome.
Click for more details
- Fast, easy entry into undilated pupils.
-
5x larger view of the fundus vs. standard ophthalmoscopes in an undilated
eye.
- 25º field of view vs. the standard 5º field of viewGreater working
distance improves comfort for both practitioner and patient.
- Detect corneal abrasions with cobalt blue filter and corneal magnifying
lens.
- Compatible with all existing Welch Allyn 3.5 V power sources.
- Compatible with all existing Welch Allyn 3.5 V power sources.
Standard Ophthalmoscope (#11710)
The Welch Allyn 3.5v Standard Ophthalmoscope is both versatile and
economical. It features halogen light for true tissue color and consistent,
long-lasting illumination and 28 focusing lenses.Click for more details
-
6 apertures: micro, small, and large spot sizes, fixation
-
Halogen light for true tissue colour and consistent, long-lasting
illumination
-
rubber brow rest prevents scratching of eyeglasses
-
target, slit aperture, and red-free filter
-
28 focusing lenses with a range of -25 to +40 diopters
Coaxial Ophthalmoscope (#11720)
The patented Welchallyn
Coaxial Vision system facilitates ophthalmoscopy by enabling easier
entry into the eye, a larger field of view, and reduced glare compared
to standard ophthalmoscopes.
Click for more details
- Halogen HPX lamp provides light for true tissue colour
and long-lasting performance
- Coaxial optics produce a shadow-free spot, easier
entry into undilated pupils, and a larger field of view versus
standard ophthalmoscopes
- Detect corneal abrasions with cobalt blue filter
- Polarising filter virtually eliminates corneal
reflection
- sealed optics keep out dust and dirt
- 18 unique aperture/filter combinations for greater
versatility
- red-free filter may be used with any aperture
- 28 focusing lenses with a range of -25 to +40 diopters
Macroview Otoscope Head Without Throat Illuminator (#23810)
Welch Allyn's MacroView Otoscope is the
next-generation otoscope that is as easy to use as your current model, but
features advanced optics for increased magnification and a nearly full view
of the tympanic membrane. Virtually eliminates the need for panning, and
simplifies seeing past wax and locating fluid behind the eardrum. Lets you
perform examinations without your glasses, thanks to the focusable eyepiece.
Twice the field of view and 30 percent greater magnification than a
traditional otoscope. Ability to adjust focus to fine tune view. Tip grip
for secure fastening of ear specula along with ejection feature for
disposal. Fiber optics produce cool light with no reflections, no
obstruction.
Click for more details
-
3.5v MacroView Otoscope
-
Ability to adjust focus for variable ear canal length or farsighted eyes
-
Tip grip for secure fastening and ejection of reusable ear specula
-
Fiber optics for cool light with no reflections
-
2 X field of view and 30 percent greater magnification than traditional
otoscopes
-
Power handles sold separately
MacroView otoscope (#23820)
MacroView Otoscope with Throat Illuminator (head only)
Delivers almost twice the field of view at higher magnification
compared to standard otoscopes, making it easier to visualise
the auditory canal and tympanic membrane. This instrument is a
significant advance in hand-held otoscopy, providing an improved
view for enhanced learning and decision making.
Click for more details
-
Better clarity and definition of landmarks
-
The ability to adjust focus for variable ear
canal length or farsighted eyes
-
Tip grip for secure fastening and ejection of
ear specula
-
Fibre optics produce cool light with no
reflections, no obstruction
3.5V Pneumatic Otoscope Head With Specula (#20200)
This 3.5v Pneumatic Otoscope set includes a rechargeable handle that is
C-Cell Convertible and a reusable ear specula set. The Otoscope uses a
Halogen HPX lamp for more light output for true tissue color and consistent,
long-lasting illumination. Its rotating lens with ultra-seal allows for
pneumatic otoscopy. Its fiber optic illumination produces cool light. It has
a 10 Diopter lens, 2.5X magnification.
Click for more details
- 3.5v Pneumatic Otoscope with Halogen Lamp
- Reusable Polypropylene Pneumatic, Operating, and Consulting Otoscope
Specula, Set of Five (2, 3, 4, 5 and 9 mm)
- Rotating lens with ultraseal
- Fiber-optic illumination
- 10 Diopter lens
- 2.5X magnification
- Rechargeable handle, C-cell convertible
- Nickel-cadmium battery included (72300)
- IEC plug type-A
3.5V Operating Otoscope Head With Specula (#21700)
The Welch Allyn 3.5v
Operating Otoscope Head with Specula has an open system, rotatable lens and
speculum for convenient procedures. It uses a Halogen HPX lamp that provides 30%
more light output for true tissue color and consistent, long-lasting
illumination. Its open system is convenient during procedures. The rotatable
lens and speculum allows ease of use and its fiber optic illumination produces
cool light.
Click for more details
-
3.5v Operating Otoscope with Halogen Lamp
-
Reusable Polypropylene Pneumatic, Operating,
and Consulting Otoscope Specula, Set of Five (2, 3, 4, 5 and 9 mm)
-
Halogen HPX lamp for true tissue color
-
Open system
-
Rotatable lens and speculum for ease of use
-
Fiber-optic illumination produces cool light
Rechargeable 3.5V Direct Plug-In Style Handle (#71000-A)
This universal rechargeable handle powers all Welch
Allyn 3.5V instrument heads. It is well-balanced and rests comfortably in the
hand. Its weight is evenly distributed end to end. It has an adjustable rheostat
control; its
free-floating reserve setting allows optimal intensity and battery life.
The convenient built-in charger allows you to plug
into any conventional wall outlet for overnight recharging. A long-lasting
rechargeable nickel-cadmium battery is included. Its smooth, non-abrasive
knurled finish ensures a no-slip grip.
Its chrome-plated brass
handles provide durable, long-life construction. It has a safety switch to
prevent accidental draining of the battery.
Metal head connectors for
durability.
Click for more details
- Universal rechargeable handle: powers all Welch
Allyn 3.5V instrument heads Adjustable rheostat control
- Free-floating reserve setting allows optimal
intensity and battery life
- Long-lasting rechargeable nickel-cadmium battery
included
- Non-abrasive knurled finish ensures
- Chrome-plated brass Safety switch to prevent
accidental draining of the battery
- Metal head connectors for durability
3.5V Rechargeable/Convertible Direct Plug-In Style Handle, 110V (#71000-C)
This is a convertible
version of Welch Allyn's universal rechargeable handle to power all Welch Allyn
3.5V instrument heads. A convenient built-in charger allows you to plug the
handle into any conventional wall outlet for overnight recharging.
The 71000C model also
includes a battery converter accessory that allows the handle be powered by
C-cell batteries, a handy feature if you're on call or have forgotten to charge
the battery. Also, the convertible handle is very useful when working overseas
or in areas where it's difficult to find electricity.The handle is well-balanced
and rests comfortably in the hand. Its weight is evenly distributed end to end.
It has an adjustable
rheostat control and a free-floating reserve setting that allows optimal
intensity and battery life. Its smooth, non-abrasive knurled finish ensures a
no-slip grip. Its chrome-plated brass handles provide durable, long-life
construction.
It has a safety switch to prevent accidental draining of the
battery. Metal head connectors for durability.
Click for more details
-
Universal rechargeable handle with battery
converter accessory: powers all Welch Allyn 3.5V instrument heads
-
Adjustable rheostat control
-
Free-floating reserve setting allows optimal
intensity and battery life
-
Long-lasting rechargeable nickel-cadmium
battery included
-
Battery converter accessory converts handles
to be powered by C-cell batteries
-
Non-abrasive knurled finish ensures
-
Chrome-plated brass
-
Safety switch to prevent accidental draining
of the battery
-
Metal head connectors for durability
-
One year Welch Allyn warranty
Lithium Ion Handle with AC Charging Module Rechargeable 120-Minute Power
Handle(s) (#71900)
Twice the on-time, half the weight, and fits more comfortably in your hand.
Click for more details
- Twice the on-time as a conventional
handle, half the weight, and fits more comfortably in your hand.
- Half
the weight of traditional 3.5 V handles
- Fits all Welch Allyn 3.5 V
instrument heads
- 120 minutes of on-time (compared to 60 minutes for
standard NiCad handles)
- Made of sturdy CYCOLOY engineering resin
- Low-battery indicator
- Lithium ion battery technology that has no “memory”
effect
- AC charging module is easily removable from the handle and has
retractable AC prongs (model 71900 only)
3.5V Nasal Illuminator Only (#26535)
The 3.5V Nasal Illuminator from Welch Allyn is three instruments in one. It
facilitates easy nasal examinations with halogen HPX illumination for true
tissue color and a reusable tip. As a bonus, the head can be detached to use the
illuminator as a throat illuminator or penlight.
Click for more details
-
Nasal illuminator
-
Halogen HPX lamp
-
Fiber optics project cool distal light
-
Detach the head to use as a throat illuminator/penlight
-
9.0 mm Reusable Specula
-
Nasal Illuminator Section requires Throat Illuminator Section (#23857)
-
Power Handle Not Included
|
|
